NeoR
Less weight - more performance
- Universal fields of application: Foundations, columns, beams, walls
- Height offset of the panels can be performed via oblong holes in the panel frame
- Well-balanced range of panels
- 90 x 150 cm panel can be used both vertically and horizontally due to internal tie-points
- A floor height of up to 3 m can be formed with just one extension
- Keybolts as lightweight, friction-locked and cost-effective connecting pieces
- Easy attachment of accessories using the hook head principle
- The structural height is just 7.5 cm → low storage and transport volume
- The flat steel frame guarantees robustness and durability
- Fresh concrete pressure capacity of 50 kN/m²
- Compatible with all PASCHAL systems
Due to the low weight (30 kg/m²), the NeoR can be moved easily by hand – ideal for construction sites, even without a crane.
| Technical Data | |
|---|---|
| Panel widths | 90/75/60/45/30/15 cm |
| Panel heights | 150/90 cm |
| Large-size panel | 180 x 300 cm |
| Frame depth | 7,5 cm |
| Plywood | 12 mm birch plywood |
| Max. concrete pressure | 50 kN/m² according DIN 18218 |
| Tolerances of deflection | According DIN 18202, table 3, line 6 |
